Kajak Model A

Model A:
The sample tube (2) is a 50 cm long acrylic tube, screwed into a POM house (1) with a built-in silicone contra flap. The shaft (8) is 4 m (2 x 2 m), and the tube is made from stainless steel with solid assembly fittings (9), which results in a lightweight, but strong construction. The sampled sediment core is visible through the transparent acrylic sample tube.








Description Ordering No.
Complete sediment core sampler with:
1 pc 50 cm acrylic tube and 4 m (2 x 2 m) shaft made of stainless steel. Tubes for model A and B are not interchangeable.
Model A
Model B
13.000
13.400
(2) 2" tube thread/sharpened, for model A
O.D./I.D. Ø60/52 mm L=50 cm, weight 0,5 kg
L=100 cm, weight 0,9 kg
13.001 A
13.011 A
(3) 2" tube
thread/thread, for model A
O.D./I.D. Ø60/52 mm L=50 cm, weight 0,5 kg
L=100 cm, weight 0,9 kg
13.002 A
13.012 A
(2) 2" tube machined/sharpened, for model B O.D./I.D. Ø60/52 mm L=50 cm, weight 0,5 kg
L=100 cm, weight 0,9 kg

13.001
13.011

(3) 2" tube
machined/thread, for model B
O.D./I.D. Ø60/52 mm L=50 cm, weight 0,5 kg
L=100 cm, weight 0,9 kg
13.002
13.012
(4) Adjustable piston rod with silicone packing L=65 cm
L=115 cm
13.003
13.013
(5) Carver, (nose piece), AISI 316 stainless steel, weight 0,2 kg 13.004
(6) Rubber bung 13.005
(7) Fraction tray for ejected sample, weight 0,4 kg 13.006
Extension shaft, stainless steel L=2 m

13.014



caution.gif Do not use alcohol for cleaning acrylic parts
