Plankton net Ø50 cm

23.020 - Plankton net, diameter 50 cm_hor
23.020 - Plankton net, diameter 50 cm:

  • Outer diameter. 50 cm
  • Length of net: 200 cm
  • Length, overall: 280 cm
  • Mesh size: 50 - 500 µm, order no. 23.020 or 20-40 µm 23.020A, please specify on order
  • Inclusive net bucket 23.021

The upper part of the net is made of strong Beaver nylon. Standard mounting with 3 pcs. of polyester line Ø5 mm. with bridles, length 80 cm.

The conical net bag with an upper diameter of 50 cm and a length of 200 cm is made of Monodur Nytal (Nylon) 50 to 500 µm. order no. 23.020 or 20-40 µm 23.020A.

The sample can be removed through a valve at the bottom of the sample cylinder.

Plankton nets are available in all types and sizes.



23.020 - Plankton net, diameter 50 cm.


23.020 - Plankton net, diameter Ø50 cm, length 200 cm.


Net bucket:

  • Sample cylinder made of POM and AISI 316 stainless steel
  • It has 3 windows, slightly offset, so you can easily pour out the content
  • The windows are covered by a net, corresponding to the
    mesh size of the main plankton net
  • The windows are protected by AISI 316 stainless steel
    net at the outer side (mesh size 10 mm)
  • Overall length: 285 mm
  • Max. width: 116 mm
  • Outer diameter of tube: 80 mm


23.023 - Net bucket with quick release for emptying.


Details:

  • Solid fastenings for the lines, using bridles and ring made
    from AISI 316 stainless steel
  • Solid hems and reinforcements











Digital flow meter:
The plankton net can be equipped with a digital flow meter (optional) for determing the amount of water passing through the plankton net. Available models 23.090 (no back-run stop) and 23.091 with back-run stop.


Details of the bridle.


23.09x - Digital flow meter (optional).


23.020 - 18 - Adapting various collecting units:




23.020 - 18 - Adapter for various collecting units.


23.020 - 18 - Adapter with a transparent collecting bottle (23.951 D), content 300 ml. Comes with a valve (not shown).


23.020 - 18 - Adapter with a glass bottle. Requires also 23.005 adapter.


23.020 - 18 - Adapter with stainless steel cylinder (23.001), content 35 ml.
