11.350 - Peristaltic pump for deep sea

11.370 - Peristaltic pump
11.3xx series - Peristaltic pump with a maximum of 18 separate channels:

The peristaltic pump is pressure compensated for use up to 6000 m depth, depending on battery used. Requires battery cylinder 100.217 for 4000 m or 100.226 for 6000 m. As standard, we provide sections with 6 channels, but other setups are also possible. Standard delivery comes without power supply and time lapse trigger. For continuous pumping simply apply a 24 V DC battery power.



A section with two open channels.


Pressure compensation for 6000 m depth.


11.350 - Peristaltic pump:
• 6 channels
• Power supply: Max. 24 V DC, recommended: 10-24 V DC
• Pressure compensated for 6000 m depth, depends on battery used
• Tubing: Ø1,5 - Ø3,0 mm, 4 or 5 mm on request.
• Motor: Detachable
• AISI 316 stainless steel
• Connector: Subconn MCBH5M
• Dim.: 570 x 130 x 200 mm
• Weight: 10 kg



11.350 - Peristaltic pump with 6 channels.


11.360 - Peristaltic pump:
• 12 channels
• Power supply: Max. 24 V DC, recommended: 10-24 V DC
• Pressure compensated for 6000 m depth, depends on battery used
• Tubing: Ø1,5 - Ø3,0 mm, 4 or 5 mm on request.
• Motor: Detachable
• AISI 316 stainless steel
• Connector: Subconn MCBH5M
• Dim.: 720 x 130 x 200 mm
• Weight 13,2 kg



11.360 - Peristaltic pump with 12 channels. Shown with mounting frame (optional).


11.370 - Peristaltic pump:
• 18 channels
• Power supply: Max. 24 V DC, recommended: 10-24 V DC
• Pressure compensated for 6000 m depth, depends on battery used
• Tubing: Ø1,5 - Ø3,0 mm, 4 or 5 mm on request.
• Motor: Detachable
• AISI 316 stainless steel
• Connector: Subconn MCBH5M
• Dim.: 920 x 130 x 200 mm
• Weight 16,5 kg



11.370 - Peristaltic pump with 18 channels.


Battery cylinder and time lapse trigger:
A complete system inclusive battery cylinder (for 4000 or 6000 m), laptop and a programmable time lapse trigger. With this option it is possible to program up to 24 individual pump sessions; running time as well as pause between each session.




Battery cylinder and accessories (optional).
